This setup will support around 700rwhp depending on injectors size without a bap and is cheaper than the frpp gt500 system while out performing it! Kit features a modifed GT hat with two ford gt supercar pumps which flow 550lph @ 13.5 volts/39psi! Also includes my fuel system wire upgrade kit which runs a 10 gauge wire with relay to the fpdm and fuel hat wire upgrade harness which runs 10 gauge power and ground wires from the fpdm to the fuel hat to support the pumps. The fuel hat is is a direct swap drop in featuring larger 3/8" gates submersible fuel hose, high flow Y fitting and stainless fuel hose clamps. The wire kits come with color installation instruction for a clean and easy install. Best value fuel kit you can buy for your S197!
Full setup is $450 with free shipping in the cont us.
*Have your own fuel hat for me to work on or have a spare you want to send me? Send me your hat and the kit is $400 including return shipping to you!
*The fuel level sender resistance reading changed in 2010 so please specify wether you need an 05-09 or a 10 style sender.
*Add $20 if you would like the pprv valve deleted off the hat with this kit.
*Requires custom tuning.
Full setup is $450 with free shipping in the cont us.
*Have your own fuel hat for me to work on or have a spare you want to send me? Send me your hat and the kit is $400 including return shipping to you!
*The fuel level sender resistance reading changed in 2010 so please specify wether you need an 05-09 or a 10 style sender.
*Add $20 if you would like the pprv valve deleted off the hat with this kit.
*Requires custom tuning.
