We are a premiere vendor for Comp Turbo Technologies. Message us for the best prices!
Made in the USA!
Made in the USA!
Last edited:
Comp turbo dealer
- Thread starter JeremyH
- Start date
Why Tripple ceramic ball bearing
The Comp Turbo TRIPLEX CERAMIC™ Turbocharger
The Comp Turbo TRIPLEX CERAMIC™ is dynamite in a small package and has a bearing system that utilizes the latest in ball bearing technology. Racing applications need turbochargers that accelerate at the fastest possible rate and the TRIPLEX CERAMIC™ bearing system allows it to do just that.
The acceleration rate of a turbocharger is a function of the rotor inertia and the friction losses in the bearing system. Conventional bearing systems have floating sleeve bearings that have an inner and outer oil film fed by lube oil under pressure from the engine lubricating system. They also must employ a stationary thrust bearing that is also fed by lube oil under pressure from the engine. The friction loss attributed to a stationary thrust bearing is proportional to the fourth power of the radius and can amount to several horsepower at the high speed at which turbochargers operate. The oil films in conventional sleeve bearing systems have significant viscosity that produces appreciable friction losses due to oil film shear when the turbocharger rotor accelerated and running at high speed. The friction losses in the sleeve bearings and in the thrust bearing result in mechanical efficiencies in the middle 90% range in conventional turbochargers. There is little or no oil film shear in ball bearings which operate with rolling friction only so that the TRIPLEX CERAMIC™ accelerates much faster than turbochargers using sleeve bearings systems.
The TRIPLEX CERAMIC™ bearing system is a proprietary design that is unique in the industry. It utilizes full compliment, angular contact ball bearings with ceramic balls. Compared with steel balls, ceramic balls in ball bearings have a number of advantages. Bearing service life is two to five times longer. They run at lower operating temperatures and allow running speeds to be as much as 50% higher. The surface finish of ceramic balls is almost smooth, producing lower friction losses and lower vibration levels. There is less heat buildup during high speed operation, they exhibit reduced ball skidding and have a longer fatigue life. All these characteristics make ceramic ball bearings ideal for use in turbochargers where they must operate at very high speeds and survive in a high temperature environment. The Full compliment bearings do now use a cage to position the balls and this additional feature, combined with the ceramic material provides a combination that has minimal friction losses. The mechanical efficiency of the TRIPLEX CERAMIC™ turbo can approach 99%, and this contributes to rotor acceleration rates that have been shown to be faster than competition.
The angular contact bearings are mounted in an elongated steel cylinder that is free to rotate in the bearing housing. The outside diameter of the cylinder is fed with lube oil and this outer oil film provides a cushion against shock and vibration. Two angular contact bearings are mounted in tandem on the compressor end of the cylinder in an arrangement that carries rotor thrust in both axial directions. A single angular contact bearing is slid ably mounted under pre- load on the turbine end of the cylinder and is free to move axially with shaft elongation when heat is conducted down the shaft from the hot turbine wheel. The elongated steel cylinder containing the angular contact bearings represents complete bearing system and can be inserted and/or removed as an assembly making the TRIPLEX CERAMIC™ turbocharger fully upgradeable, serviceable and re-buildable.
Racing Applications require a turbocharger that builds boost as rapidly as possible, thus allowing the engine develop high torque at low engine speeds and with boost capability that can produce very high maximum power output .The TRIPLEX CERAMIC™ turbocharger does exactly that. For example when mounted on one dragster, the TRIPLEX CERAMIC™ produced 1.7 bar boost in two tenths of a second and developed 650 HP ready for takeoff. Now that's phenomenal response and very impressive.
In street applications, the acceleration rate of a vehicle equipped with a TRIPLEX CERAMIC™ turbocharger is enhanced and moves the engine out of inefficient operating regimes more rapidly. An improvement in number of gallons of fuel used is the usual result when a vehicle is accelerated faster. Under steady-state operation, the lower HP losses in the TRIPLEX CERAMIC™ ball bearing system means power is available to the turbocharger compressor which results in higher intake manifold pressure. In most cases, higher boost can make an additional contribution to improving engine fuel consumption.
Comp Turbo can supply the TRIPLEX CERAMIC™ turbocharger with various compressors and turbine wheel trims to tailor its performance so that it matches specific engine application requirements; whether they be racing, street or stationary. In addition, the TRIPLEX CERAMIC™ will be followed in the near future by other model sized now under development at Comp Turbo. These new models will utilize the proprietary technology that has been designed into the successful TRIPLEX CERAMIC™ to complete a line of high performance turbochargers utilizing the many advantages of ceramic ball bearings. They will also accelerate like greased lightning to produce the ultimate in engine and vehicle response. For further information please contact our technical support department.
The Comp Turbo TRIPLEX CERAMIC™ Turbocharger
The Comp Turbo TRIPLEX CERAMIC™ is dynamite in a small package and has a bearing system that utilizes the latest in ball bearing technology. Racing applications need turbochargers that accelerate at the fastest possible rate and the TRIPLEX CERAMIC™ bearing system allows it to do just that.
The acceleration rate of a turbocharger is a function of the rotor inertia and the friction losses in the bearing system. Conventional bearing systems have floating sleeve bearings that have an inner and outer oil film fed by lube oil under pressure from the engine lubricating system. They also must employ a stationary thrust bearing that is also fed by lube oil under pressure from the engine. The friction loss attributed to a stationary thrust bearing is proportional to the fourth power of the radius and can amount to several horsepower at the high speed at which turbochargers operate. The oil films in conventional sleeve bearing systems have significant viscosity that produces appreciable friction losses due to oil film shear when the turbocharger rotor accelerated and running at high speed. The friction losses in the sleeve bearings and in the thrust bearing result in mechanical efficiencies in the middle 90% range in conventional turbochargers. There is little or no oil film shear in ball bearings which operate with rolling friction only so that the TRIPLEX CERAMIC™ accelerates much faster than turbochargers using sleeve bearings systems.
The TRIPLEX CERAMIC™ bearing system is a proprietary design that is unique in the industry. It utilizes full compliment, angular contact ball bearings with ceramic balls. Compared with steel balls, ceramic balls in ball bearings have a number of advantages. Bearing service life is two to five times longer. They run at lower operating temperatures and allow running speeds to be as much as 50% higher. The surface finish of ceramic balls is almost smooth, producing lower friction losses and lower vibration levels. There is less heat buildup during high speed operation, they exhibit reduced ball skidding and have a longer fatigue life. All these characteristics make ceramic ball bearings ideal for use in turbochargers where they must operate at very high speeds and survive in a high temperature environment. The Full compliment bearings do now use a cage to position the balls and this additional feature, combined with the ceramic material provides a combination that has minimal friction losses. The mechanical efficiency of the TRIPLEX CERAMIC™ turbo can approach 99%, and this contributes to rotor acceleration rates that have been shown to be faster than competition.
The angular contact bearings are mounted in an elongated steel cylinder that is free to rotate in the bearing housing. The outside diameter of the cylinder is fed with lube oil and this outer oil film provides a cushion against shock and vibration. Two angular contact bearings are mounted in tandem on the compressor end of the cylinder in an arrangement that carries rotor thrust in both axial directions. A single angular contact bearing is slid ably mounted under pre- load on the turbine end of the cylinder and is free to move axially with shaft elongation when heat is conducted down the shaft from the hot turbine wheel. The elongated steel cylinder containing the angular contact bearings represents complete bearing system and can be inserted and/or removed as an assembly making the TRIPLEX CERAMIC™ turbocharger fully upgradeable, serviceable and re-buildable.
Racing Applications require a turbocharger that builds boost as rapidly as possible, thus allowing the engine develop high torque at low engine speeds and with boost capability that can produce very high maximum power output .The TRIPLEX CERAMIC™ turbocharger does exactly that. For example when mounted on one dragster, the TRIPLEX CERAMIC™ produced 1.7 bar boost in two tenths of a second and developed 650 HP ready for takeoff. Now that's phenomenal response and very impressive.
In street applications, the acceleration rate of a vehicle equipped with a TRIPLEX CERAMIC™ turbocharger is enhanced and moves the engine out of inefficient operating regimes more rapidly. An improvement in number of gallons of fuel used is the usual result when a vehicle is accelerated faster. Under steady-state operation, the lower HP losses in the TRIPLEX CERAMIC™ ball bearing system means power is available to the turbocharger compressor which results in higher intake manifold pressure. In most cases, higher boost can make an additional contribution to improving engine fuel consumption.
Comp Turbo can supply the TRIPLEX CERAMIC™ turbocharger with various compressors and turbine wheel trims to tailor its performance so that it matches specific engine application requirements; whether they be racing, street or stationary. In addition, the TRIPLEX CERAMIC™ will be followed in the near future by other model sized now under development at Comp Turbo. These new models will utilize the proprietary technology that has been designed into the successful TRIPLEX CERAMIC™ to complete a line of high performance turbochargers utilizing the many advantages of ceramic ball bearings. They will also accelerate like greased lightning to produce the ultimate in engine and vehicle response. For further information please contact our technical support department.
Last edited:
Billet compressor wheel
Comp Turbo X-HF billet compressor wheel
After intense research and development the X-HF billet compressor wheel design flows 15-20% more air flow than prior impeller designs. The X-HF line is machined from high grade billet aluminum for durability and lower inertia. Comp Turbo X-HF line is the most advanced compressor wheel design and was engineered for maximum performance output. Comp Turbo engineering department did not make slight changes to existing compressor wheels available and replicate them out of billet. Please contact our sales staff for any questions regarding our product.
Horsepower rating starting at 300 to 2200HP
Available with
Comp Turbo X-HF billet compressor wheel
After intense research and development the X-HF billet compressor wheel design flows 15-20% more air flow than prior impeller designs. The X-HF line is machined from high grade billet aluminum for durability and lower inertia. Comp Turbo X-HF line is the most advanced compressor wheel design and was engineered for maximum performance output. Comp Turbo engineering department did not make slight changes to existing compressor wheels available and replicate them out of billet. Please contact our sales staff for any questions regarding our product.
Horsepower rating starting at 300 to 2200HP
Available with
- Polished bearing housing
- Carbon seal or Dynamic seal
- Polished compressor housing
- Ceramic coated turbine housing
- Powder coated compressor housing
- T2, T3, or T4 turbine housing options
- Now available in Oil-Less Ball Bearing
- 10 bladed lightweight 713C turbine wheel
- Available with anti-surge compressor cover
- Billet aluminum oil cooled or water cooled bearing housing
- Billet lightweight 7/14 blade high efficiency compressor wheels
- Triple ceramic ball bearing or standard 360 degree thrust bearing
Last edited:
Bobby
turbo gt about to go fast
here is a pic of he comp turbo on my car
Bobby
turbo gt about to go fast
here are some pics of the turbo from my car with the high temp coating.
Thanks for the order Benjy!
Bobby
turbo gt about to go fast
cant wait to see some pics and videos.
Thanks for the orders guys!
Did he happen to order 2 - 67mm BB units?
How is "The Beast" coming along?
Yup he did! lol
LOL, starting to make sense now, he also bought ss t4 flanges and vband flanges so I figured there was going to be some custom setup beign made!
Oil-less flavor, mmm.....
Tripple ceramic ball bearing oil-less, I can't wait to get mine on!
Michael's Billet 76 tripple ceramic oil-less.
Bobby
turbo gt about to go fast
looks bad ass
mikeyfitz
Resident Fuktard
I think I need to upgrade from my 67mm on3 lol
mikeyfitz
Resident Fuktard
Shoot me some pricing for the options you got my man.
