CAD Models - 3V

Discussion in 'Mustang Chit Chat' started by eighty6gt, Mar 11, 2019.

  1. eighty6gt

    eighty6gt forum member

    3,188
    121
    I found one of the coyote, fantastic!

    But have not run across one for the 3V engine.

  2. cavero

    cavero forum member

    486
    8
    If there were some available, I'd definitely hit up my brother for his 3D printer

  3. LikeabossTM

    LikeabossTM forum member

    213
    21
    Feel like sharing the coyote CAD?

    Sent from my Pixel 2 using Tapatalk

  4. Flusher

    Flusher Junior Member

    41
    13
    ^^^ X2

  5. eighty6gt

    eighty6gt forum member

    3,188
    121
    No!

  6. LikeabossTM

    LikeabossTM forum member

    213
    21
    Just to be sure...[​IMG]

    Sent from my Pixel 2 using Tapatalk

    eighty6gt likes this.
  7. tjm73

    tjm73 of Omicron Persei 8 S197 Team Member

    8,654
    186
    So........ you are hoping someone will give up such a file for the 3V, but you are not willing to share the file you have???? riiiiiiiiiiggghhtttt.........

    eighty6gt likes this.
  8. eighty6gt

    eighty6gt forum member

    3,188
    121
    I don't want to give up my competitive advantage in the marketplace!


  9. Flusher

    Flusher Junior Member

    41
    13
    Are you planning on producing billet blocks?

  10. fdjizm

    fdjizm Drag Queen

    18,999
    113
    I want a little 3d printed 3v model for my desk at work, make it happen.

  11. eighty6gt

    eighty6gt forum member

    3,188
    121
    sometime I will locate only the outer features of the engine and the positions of the header flanges, that's about it - will need to find a dead 4.6 3V first, or buy a car and take the engine out. I have access to 3d scanning equipment.

    That's all I have planned.

  12. NickD87

    NickD87 forum member

    561
    4
    This is prob a good place to ask.
    Does anyone have a spare set of heads to copy the placement of intake runners and water jackets from.
    I have a DOB blower and want to make an insulating spacer between the heads and manifold. Jason was going to produce this and got sued. Another guy was going to make some but got distracted.
    I have no intention to resell these just want to get a local shop to make me and a friend a set before our first track day May 13.
    Im willing to pay if needed.

    Sent from my Pixel 2 XL using Tapatalk

  13. MrAwesome987

    MrAwesome987 forum member

    Age:
    23
    64
    13
    Jason now makes a composite lower manifold piece. I am getting one for my GenIIR. He is charging $200.

  14. NickD87

    NickD87 forum member

    561
    4
    I have the gen 1 manifold they are not compatible

    Sent from my Pixel 2 XL using Tapatalk

  15. MrAwesome987

    MrAwesome987 forum member

    Age:
    23
    64
    13
    Oh, I did not realize that.

  16. Dreadknought

    Dreadknought HOON MONSTER

    1,047
    2
    Following this to see if it goes anywhere. I also have similar interests in prototyping.

  17. MrAwesome987

    MrAwesome987 forum member

    Age:
    23
    64
    13
    If someone wants to fund the price of a junkyard block, I'd be glad to model it ;)

  18. eighty6gt

    eighty6gt forum member

    3,188
    121
    you're a wild man! For free??!?!

  19. MrAwesome987

    MrAwesome987 forum member

    Age:
    23
    64
    13
    Sure I would love to have a mini 3d printed 4.6 lol it would be quite the project, and take a lot of time, but I've got a decent amount of experience in AutoDesk Inventor.

  20. eighty6gt

    eighty6gt forum member

    3,188
    121
    there are getting to be a crop of 3d scanner operators in most centers that would just do the block/head/etc.. for a reasonable cost.

    Problem is the model is an unweildy hunk of junk. 1 terabyte.
