S&H Tubular Radiator Support

[JeremyH]

Due to interest we will be selling just the radiator support we designed for our turbo kits. Available with or without the intercooler support braces as a no cost option and can be run with or without a front sway bar. Also if you want something custom just let us know. Made in USA, all steel construction, tig welded, they drop weight while freeing up room for piping, hoses or just working on the front of the engine while in the car.

Price is $110 plus shipping no coating. $150 plus shipping for your color choice of powder coat finish.



[JeremyH]

For just the sway bar delete brace no intercooler legs and no sway bar provision mounts its $75 plus shipping your choice of powder coat or paint finish.



[SSStang]

What does it weight compare to the stock piece?



[JeremyH]

What does it weight compare to the stock piece?

The stock rad support and sway bar is 26lbs.

The sway delete version like on my car with intercooler legs is 5lbs. So would weight less than that without the intercooler support legs.

Will weigh the sway bar retention one here soon after coating.



[Bobby]

This piece only weighs 6lbs



[Bobby]



[Bobby]

Here is a few pis before and after of it. This one is for a customer who didnt need to intercooler mounts. This piece comes standard in both our single turbo kit and the twin turbo kit but will have sway bar mounts like the bottom picture.



[JoshK]

Is there a price for no sway bar mounts but with the intercooler support?



[Bobby]

yes we can make it like that text me josh



[gray1622]

How far does this lower the sway bar compared to the brackets that come with 0n3 Kit?



[JeremyH]

It doesnt lower it, it rotates and moves the mounts back while moving the cross bar foward to provide a 4-5" gap between the sway bar and the support bar.
