Jordan

Junior Member
Joined
Sep 25, 2019
Posts
29
Reaction score
5
Location
Oklahoma
Looking for tips of your supercharger install!

Any special things you did that weren’t in the instruction manual?

Any videos out there that are very helpful?



stkjock

---- Madmin ----
Staff member
Administrator
Super Moderator
S197 Team Member
Joined
Jul 10, 2007
Posts
40,237
Reaction score
3,149
Location
Long Island NY
might want to indicate what system you're considering and search the site, many write ups on installs


golkhl

forum member
Joined
Feb 12, 2010
Posts
4,341
Reaction score
2,720
Location
Las Vegas, NV
Bag and label everything you remove during disassembly. Lay out the entire kit before you start the install to make sure you are not missing any parts or hardware.


FredB66

Member
Joined
Mar 4, 2019
Posts
150
Reaction score
124
Location
Grapevine, TX
Is this a full system or tuner kit (fuel system upgrades and tune not included)? Suggestions and tips will vary greatly depending on what you are installing.


07 Boss

Senior Member
Joined
Jan 25, 2009
Posts
3,844
Reaction score
978
Location
Sin City
The actual hardest part of my install was getting the fuel pump in. Seems like Ford failed to line the access hole to actually line up with the pump hat. If you unbolt the straps to your tank and let it drop down a few inches it will give you some more wiggle room to maneuver and install the pump.


AHaze

Member
Joined
Dec 31, 2019
Posts
309
Reaction score
171
Location
Edmonton, AB
I put an IAT sensor in the manifold. The stock IAT sensor is in the MAF meter so (assuming you're using the Paxton supplied draw thru setup) the ECU can't see charge air temp changes.

Joined
Feb 11, 2021
Posts
487
Reaction score
400
Location
29486
I don't mean to sound like sour grapes and I'm no mechanic but I have heard that if you install this system when it becomes heat soaked your advantage dwindles. Just saying.


tabstang

Member
Joined
May 15, 2017
Posts
119
Reaction score
43
Take lots of detailed photos b4 and keep them for future reference. Be systematic and take notes and use the instructions as a checklist. HIGHLY recommend the Gates RPM belt, way less stretching and much better power transfer. Solved a huge problem on my whipple setup.

I've done both "turbo" (like yours) and twin screw types, the one you're doing is pretty simple and easy, at least by comparison. I would plan on a full weekend in the garage - then the fun begins! Beware snap oversteer!


Oliver Vigil

Member
Joined
Jul 7, 2019
Posts
57
Reaction score
7
Is this a full system or tuner kit (fuel system upgrades and tune not included)? Suggestions and tips will vary greatly depending on what you are installing.

run a Boost a pump and larger injectors, all you'll need for the fuel system. Install is extremely straight forward, just take your time and keep track of what's being uninstalled. The routing of your oil lines is pretty critical, I had one rubbing on my crank pulley and ate a hole into the braided line. Paxton provides detailed instructions that got me threw the install without additional instructions needed.


AHaze

Member
Joined
Dec 31, 2019
Posts
309
Reaction score
171
Location
Edmonton, AB
I don't mean to sound like sour grapes and I'm no mechanic but I have heard that if you install this system when it becomes heat soaked your advantage dwindles. Just saying.
That's true of all forced induction setups. What matters is how hard you can run it before that happens.
One of the selling points of centrifugal blowers is that they have better adiabatic efficiency than PD blowers. My personal experience with a Vortech Si (same blower as the Novi 1200) has included zero heat soak. IATs at my 9psi max are within 20° of ambient.

Joined
Feb 11, 2021
Posts
487
Reaction score
400
Location
29486
When you do the boost pump make sure you install a bigger fuse. I blew my once and thought I deadlined the car and it was just a fuse.


ashfope

Junior Member
Joined
Jul 25, 2007
Posts
1
Reaction score
0
I have a boost pump since 2007. The fuse has never blown. Maybe the wrong fuse was included; however, I would recommend against doing that from the get go. Fuses are sized by the wire they are protecting. Contact the vendor to see if they've had a fuse problem, and then go with their recommendation.


Pentalab

forum member
Joined
Mar 5, 2013
Posts
5,214
Reaction score
1,103
Don't forget to supercharge the suspension, brakes, and tires.


saleen836

forum member
Joined
Dec 9, 2008
Posts
748
Reaction score
659
Location
Across the pond!
You might want to think about putting a larger pulley on your alternator or you could find it breaking down in a short space of time

Joined
Feb 11, 2021
Posts
487
Reaction score
400
Location
29486
I have a boost pump since 2007. The fuse has never blown. Maybe the wrong fuse was included; however, I would recommend against doing that from the get go. Fuses are sized by the wire they are protecting. Contact the vendor to see if they've had a fuse problem, and then go with their recommendation.
My shop called Brenspeed and in this particular set-up the fuse had to be upgraded for the Paxton 2200SL paxton.


07 Boss

Senior Member
Joined
Jan 25, 2009
Posts
3,844
Reaction score
978
Location
Sin City
Stops the alternator spinning to fast and failing, I believe the Saleen SC kit comes with a different pulley for the alternator

Oh I thought it was something to do with installing the supercharger. I mean the engine still spins at the same speeds, it's not like the alternator gets spun faster with an SC on there. Seems kinda counter productive. I feel better with my alternator spinning as fast as it should, not that I have a bunch of electronics or anything, but it just seems weird to want to slow it down,
