Eibach pro-kit lowering springs installation advice

hugh

Junior Member
Joined
Jul 7, 2018
Posts
14
Reaction score
0
im sure theres million threads on this but i need quick advice
i have a 2007 mustang gt ive settled on the Eibach pro kit springs because they claim it wont quite be 1.5 inches but close anyway my question is is there anything else you guys who are experienced in lowering our cars think i will need, i have
the pro kit springs
whiteline adjustable panhard bar
koni shocks and struts
whiteline lower control arms.
anything else i should get before i start working on it, and im also going to get an alignment after we're through installing them... thanks in advance


oldVOR

forum member
Joined
Apr 9, 2015
Posts
1,754
Reaction score
484
Location
Northern Virginia
Much of the OEM hardware is one time use and should be replaced.
The strut bolts and nuts should be upgraded to the '11-14 fine pitch hardware.
Remember to keep the LCA/UCA/PHB hardware loose and tighten it with the suspension loaded.


RED09GT

Equal Opportunity Offender
S197 Team Member
Joined
Jul 17, 2009
Posts
2,630
Reaction score
488
Location
Kelowna, B.C. Canada
Lower control arm brackets would be a good addition.
I've re-used most of the suspension bolts numerous times and they have held their torque values. The front sway bar end links are the only ones that I had trouble with.
The service manual calls for a torque value rather than a torque and an angle so most of the bolts on an 05-10 can be re-used.


hugh

Junior Member
Joined
Jul 7, 2018
Posts
14
Reaction score
0
thank both of yall very much i will be getting the brackets and up grading to 11-14


TheDarkPath

forum member
Joined
Oct 20, 2007
Posts
187
Reaction score
4
Location
Houston, TX
Upper strut mounts are a good upgrade to do while you are in there. I didn't upgrade mine when I first lowered my 06 GT and after some time, one failed and starting having a clunk/pop noise. I replaced mine with MM caster camber plates but you can get GT500 upper mounts as an upgrade as well.


Stevejr

Junior Member
Joined
Dec 18, 2018
Posts
17
Reaction score
7
I just lowed mine with some cheap springs from American muscle. Dropped it around 1.25in. I didnt have to replace anything other than the upper strut mounts. One accidently came apart sk I replaced both.



07 Boss

Senior Member
Joined
Jan 25, 2009
Posts
3,831
Reaction score
968
Location
Sin City
One thing that worked well when I installed my ProKit springs was that I clocked my strut mounts 180*. This will bring your camber back to factory spec or at least closer to spec. It will wear them faster but you shouldn't have to make any camber adjustments for the drop.


Geosh

Junior Member
Joined
Mar 15, 2019
Posts
40
Reaction score
15
Or get some camber plates while you have it all apart. That is what I did on my first Mustang and it allowed me to dial in the alignment just right.


07 Boss

Senior Member
Joined
Jan 25, 2009
Posts
3,831
Reaction score
968
Location
Sin City
Or get some camber plates while you have it all apart. That is what I did on my first Mustang and it allowed me to dial in the alignment just right.

Yes the proper way to do it would be to buy some camber plates or some adjustable strut mounts. But for a mild drop you might not be out of spec and if you are it is going to be minimal. The clocking of the strut mounts is a simple, inexpensive way to adjust the camber that may or may not work, but in most cases it will. Once I went lower I did need some more adjust-ability but I have since raised it back up a bit. My strut mounts are currently in the proper orientation and I have just over -2* on the drivers side and about 2.5* on the passenger side. I actually like it this way as it feels there is more bite on initial turn in.


Forty61

forum member
Joined
Nov 6, 2016
Posts
1,166
Reaction score
1,060
Location
Dallas, TX
Bunch of good suggestions in here. I used the Pro Kit with some fresh strut mounts, adjustable PHB and that was it, been running and riding great for years.


hugh

Junior Member
Joined
Jul 7, 2018
Posts
14
Reaction score
0
for the strut mounts im looking on AM and they have OPR replacement mounts or gt500 upgrade which would yall recommend or which did you use


06 T-RED S/C GT

forum member
Joined
Jan 8, 2016
Posts
2,270
Reaction score
369
Location
Carnegie, PA
Unless your lowered by 1.5"or more? bumpsteer kits are not necessary. The Eibach pro kit springs lower the front suspension by no more than 1.3" max. I've ran the pro kit springs for many years with just GT500 strut mounts, BMR adjustable PHB, Eibach camber bolts and Koni yellow adjustable strut/shocks. Both caster/camber alignment are within Ford factory specs. However it would be recommended to add a bumptsteer kit with the Eibach sport spring kit which lowers the front suspension approx 1.7"

Last edited:

hugh

Junior Member
Joined
Jul 7, 2018
Posts
14
Reaction score
0
thanks im ordering some gt500 strut mounts and already have adjustable PHB, KONI orange shock and struts (got them last christmas for a gift) whats yalls opinion of the KONI str.t orange shocks and struts??


bujeezus

forum member
Joined
Aug 31, 2015
Posts
3,251
Reaction score
355
Location
Alabama
Camber bolts and clock your strut mounts 180* should cover it. I'm lowered 2" all around and my alignment shop offered me a job when I told them it was a "driveway alignment". Lol!


TANN3R_

Junior Member
Joined
Jan 6, 2020
Posts
28
Reaction score
6
Location
Czech Republic
hello,
I planning to lower my 05GT with the Eibach pro kit. I just can´t find the rear spring insulators. Is there some eshop, where I can get them?

Now I have the H&R coilover kit on car, wich I already bought with the car, so I don´t have the original factory insulators..

Thank you in advance.


JEWC_Motorsports

S197 Junkie
S197 Team Member
Joined
Aug 22, 2010
Posts
20,471
Reaction score
1,596
Location
Texas
KONI orange shock and struts (got them last christmas for a gift) whats yalls opinion of the KONI str.t orange shocks and struts??

Several people have had them leak after a yr or so of driving. I had both leak, warrantied and then the new set leaked. My opinion is they are junk.
